Capability Gating Is Not Authorization

Sources#

• Capability Gates Are Not Authorization: Confused-Deputy Failures in LLM Agent Frameworks
• OpenID Foundation advances authorization for the agent era with new AuthZEN Working Group Drafts

Summary#

David Mellafe Zuvic (Independent Security Research, Chile; arXiv 2606.28679, June 2026) audits a specific authorization failure in tool-using LLM agents: capability gating is present, but per-call authorization is absent. The two are distinct controls that frameworks routinely conflate:

• Capability gating is static — it decides which tools exist in the agent's menu (tool allow-lists, key scopes, JSON schemas). A schema can reject a malformed argument.
• Per-call authorization is dynamic — it decides whether this concrete call, with these argument values, in this principal/session context, is allowed. A schema cannot decide whether a well-typed account=acct_ATTACKER_999 is authorized.

When the only checks are tool-name existence and schema validity, "the untrusted model effectively supplies both the action and the authorization fact." That is the confused deputy (Hardy 1988): a privileged component induced by attacker-controlled input to misuse its authority. Classical systems security already gives the remedy — Saltzer–Schroeder complete mediation: every access to authority must be checked, not only at construction time. This is empirical work: a reproducible cross-framework audit tied to a measured threat and a deployable control, with no CVE asserted and no live third-party service attacked.

The paper is the authorization layer the vault's injection-attack pages exploit. Agentic Prompt Injection and its finer variants (Agent Data Injection (ADI), Task-Specification Effects in Prompt Injection (AutoDojo)) are all delivery mechanisms that end in a model-emitted tool call; this paper takes injection as given and studies the narrower systems question: once a compromised model emits a call, what does the runtime do next?

The two controls, and why conflating them is a confused deputy#

The system is a tool-using agent embedded in an application that holds real authority (a payment key, mailbox, CRM token, HTTP egress, MCP client, infra credential). The agent runtime and tools are inside the trust boundary; the LLM is not — it is an untrusted parser/planner over text that may include attacker content. The adversary controls content, not code (a retrieved document, web page, email body, support ticket, prior tool output, or agent-to-agent handoff) and wants the agent to emit a side-effecting call with attacker-chosen arguments: repoint a payout account, refund to an attacker destination, exfiltrate a secret, fetch an SSRF target. This is indirect prompt injection (OWASP LLM01, MITRE ATLAS AML.T0051) — assumed feasible, not re-litigated.

Compromise-source independence is the boundary's key property. Runtime prompt injection and supply-chain model compromise converge at the action layer: both produce a proposed tool call. A poisoned checkpoint can carry a file-level RCE (unsafe deserialization, trust_remote_code) or a weight-level backdoor whose trigger phrase elicits an attacker action — and weight-backdoor detection is an open problem. At the per-call boundary both are treated identically: a backdoor-triggered update_payout_account(acct_ATTACKER) and an injection-triggered one are denied by the same out-of-band policy. The control contains the action-layer consequence for governed tools; it does not detect poisoning, recover a clean model, or constrain non-tool text returned to the user.

Out-of-band policy is load-bearing#

The policy the gate checks against is not model output. Tool scopes, allowlists, money ceilings, idempotency requirements, and verified sets like {acct_MERCHANT_001} are operator-authored configuration loaded from a root of trust outside the model's context window, write path, and influence. Injected content can move the proposed call from account=acct_MERCHANT_001 to account=acct_ATTACKER_999; it cannot move the verified set the proposal is checked against. A design in which the LLM emits, expands, or discovers its own per-call scope would be circular — the same injection that corrupts the call could corrupt the scope. The obligation is transitive: no policy element may be sourced (directly or indirectly) from any model output at any stage — offline authoring, session seeding, or runtime refresh — which excludes verified-set poisoning, session-seeded time-of-check/time-of-use policy mutation, and dynamic policy fetch over model-reachable egress. This is the same doctrine the out-of-band defense literature states as "the gate must not be a model."

The cross-framework gap (Table I)#

A public-source architecture audit at pinned commits asks one narrow question: after the model emits a tool call, is there a deterministic fail-closed authorization check over the concrete argument values before side effect? All three audited stacks ship capability gating; none ships that check by default:

Framework (pinned source)	Capability gating	Per-call value authorization (default)	Confused-deputy by default
LangChain / LangGraph (00ad96c / bdb323e)	yes	none — callback hooks are observability, not a mandatory veto; HITL middleware is integrator-wired	yes
LlamaIndex (v0.14.23, 520aa4e)	yes	none at central tool dispatch; fn_schema is shape metadata; HITL is tool-author workflow code	yes
Stripe Agent Toolkit (0b4961f / f54c9e6)	yes	none on money args (amount, customer, payment_intent, destination, redirect_url); action allowlist + Restricted API Key scope are coarse, not per-transaction	yes

In each default dispatch path the model-selected tool name is resolved, input shape is validated, and the tool is invoked with the model-supplied arguments — with no hook between validation and execution that consults an authorization policy over concrete values. Stripe is highest-stakes because it sits nearest money movement. The audit is of public client/framework defaults (Stripe's remote MCP internals were not audited) — candidates for hardening and standards clarification, not asserted vulnerabilities.

How exposed is the model? (Table II / Figure 1)#

The gap matters only if real models emit unauthorized calls under realistic attack. A companion 27-model deterministic benchmark ([16]) measures ASR = the model's attempt rate (issuing an unauthorized call or producing an exact SHA-256 canary under a deterministic oracle in a sandbox with non-routable sinks) — not a breach rate. Two signals:

• Deployment-tier vs flagship. Cost-optimized "deployment-tier" models (economical, suited to high-volume agent traffic) attempt the unauthorized call ~3.2× more often than flagships: mean ASR_task 0.603 vs 0.189 (verified against Figure 1). Deployment-tier exemplars: gpt-4o-mini 1.000, glm-4.5-air 1.000, gemini-3.1-flash-lite 0.980; flagship low exemplars: glm-5.2 0.087, gemini-3.1-pro-preview 0.000. The tier is an economics inference, not a disclosure that any vendor runs a named model in production, and the aggregate carries no paired CI (high outliers exist in both groups).
• Task-aligned framing — presenting the same dangerous action as required to complete the user's task — sharply raises attempts over a crude naive injection: glm-4.7 0.283→1.000 (Δ0.717, BH q<0.001), gemma-3-12b-it 0.000→0.571, mistral-large 0.027→0.459 (paired, Wilson/Newcombe CIs, Benjamini-Hochberg correction). This is the same "the injection reads as task-data, not as an instruction" mechanism AutoDojo measures on the defense side. A Latam-GPT sovereign-model vignette shows an EN/ES sign flip (0.320→0.520 vs 0.240→0.040) but is caveated as a modality floor (bnb-4bit, native function-calling disabled), not a causal claim.

ScopeGate: a deterministic 5-stage PDP/PEP (Figure 3, Algorithm 1)#

ScopeGate is a Policy Decision Point / Policy Enforcement Point that sits downstream of the model and upstream of side-effecting tools. It receives a proposed (tool, args) plus trusted context and returns ALLOW / DENY; no LLM participates in the decision. It evaluates five stages in order and fails closed on any miss or runtime error:

1. Scope — is this tool governed by policy? Unlisted tools → DENY. Blocks model-discovered tools and misspelled variants from reaching side effects.
2. Authorization — are value-constrained arguments in their allowlists? This is the missing framework check. A well-typed but unauthorized account, destination, customer, URL, or payment intent → DENY(authz).
3. Money ceiling — for payment/refund tools the amount must be a finite real in [0, ceiling]. An affirmative check, not a naive > comparison: NaN, infinities, complex values, booleans-as-integers, and non-numeric containers all deny.
4. Idempotency — side-effecting tools that require it must receive a trusted idempotency key in context; a missing key denies, limiting replay and loop amplification.
5. Default deny — only calls passing every stage are allowed; errors are treated as denial. "A policy engine that fails open on malformed input recreates the vulnerability with extra steps."

The security property is placement-independent as long as all side-effecting calls pass through the PEP and policy stays out-of-band: it can live as SDK middleware inside the app, a sidecar proxy on loopback, or a central egress/MCP gateway (the evaluation uses SDK placement).

Evaluation (Table III)#

• Reproducible framework PoC. Real LangChain tools (update_payout_account, issue_refund) over a mocked merchant backend; a fixed compromised output proposes update_payout_account(account=acct_ATTACKER_999). Part A (normal dispatch) applies the attacker account and records a side effect; Part B routes the identical call through ScopeGate, which denies at authz (not in {acct_MERCHANT_001}) with zero side effects. A companion LlamaIndex PoC reproduces the same default-dispatch gap. One command (./run_proof.sh, Apache-2.0 artifact at commit d9568ac) reproduces it.
• Static bypass suite — 0/48. 48 adversarial vectors (case/whitespace/zero-width/homoglyph/null-byte mutations, type confusion, unhashable arguments, tool-name mutations, money edge cases, missing idempotency); none allowed. The suite found and fixed a real fail-open in an earlier ScopeGate prototype — NaN passed a naive money comparison — now denied at the money stage (a ScopeGate prototype bug, honestly reported, not a framework fail-open).
• Adaptive attacker — 0/29. Deny reasons fed back to a GLM-5.2 attacker for 40 iterations: 0/29 unauthorized attempts allowed (29 denied, 9 malformed/parse errors, 2 benign allowed). Budget-bounded, not a universal proof.
• Benign controls — 0 false-denies. 0/10 false-denies across two deployment-tier native-function-calling models; a deterministic Latam-GPT probe separately allows 4/4 authorized actions.
• Payment-agent containment. In a WhatsApp payment replica under a Business-Email-Compromise framing, glm-4.5-air and gpt-4o-mini both attempt the unauthorized payout 10/10; ScopeGate denies every out-of-scope payout at authz (0/5 false-denies per model on benign controls). A Latam-GPT Spanish PCI re-tokenization run: 10/10 unauthorized attempts, 10/10 denied at authz; the broader battery records 11/11 harm-bearing egress actions denied.

Positioning and limitations#

The paper is deliberately narrow. It does not claim to discover prompt injection or the first per-call authorization for agents — MiniScope (arXiv:2512.11147) exists and least-privilege predates LLM agents. The defended novelty: the first reproducible cross-framework audit of the exact default gap "capability gating shipped, per-call authorization absent," paired with measured model exposure and a deployable fail-closed control. It is compatible with cryptographic payment consent (the AP2-break line [11]): even strong payment rails need a deterministic control plane that checks model-proposed transactions against operator policy before execution.

The limits are stated plainly: containment is not cure (ScopeGate does not prevent injection, detect poisoned weights, repair model behavior, or guarantee safe natural-language output — it bounds what a compromised model can do through governed tools); the 0/48 and 0/29 figures are suite- and budget-bounded, with longer adaptive budgets, stateful side channels, DNS rebinding, timing, and multi-agent policy-poisoning left as future work; and the audit is public-source only, so its findings are hardening candidates, not CVEs.

How this answers "attacks confined to already-authorized actions"#

Out-of-Band Prompt-Injection Defense carries an open question the attack papers keep sharpening: does an attack confined to already-authorized actions — one that achieves the injection goal without any policy violation — slip past a deterministic action gate the way adaptive attacks broke in-band defenses? This paper names that failure class precisely and offers a defense. "Already authorized" splits into two:

• Capability-authorized but not value-authorized — the tool (issue_refund, update_payout_account) is in the granted menu, but the injected argument value (attacker destination/account) is not. This is the confused-deputy-within-scope case, and ScopeGate blocks it at the authz stage by re-checking values against out-of-band allowlists (0 bypasses in the tested corpus). The attack that looks like "within already-granted capability" becomes a policy violation at the value level.
• Genuinely within policy — the corrupted value legitimately varies and is not allowlist-constrainable (free-text content, an in-range amount to any legitimate customer, or the spoofed author / fabricated tool result the agent legitimately acts on). Here the action satisfies the value policy while still doing harm. This is the same residual ADI showed against Progent (22.2%) and the "in-the-loop / text-to-text" limit the out-of-band page names — a limit ScopeGate shares by construction, because a value gate only helps where a policy constrains the corrupted argument.

So the honest reading: per-call value authorization closes the value-redirection class of within-capability attacks (a real advance over capability-gating-only defaults) but not the corrupt-legitimately-variable-data class, which needs provenance/data-flow tracking. It is a defense in kind — a deterministic capability-removal, per Impossible, Not Tedious (Design Test) — not a cure.

The standards-track counterpart (OpenID AuthZEN / COAZ)#

ScopeGate is a measured research system; the OpenID Foundation's AuthZEN Working Group is standardizing the same "authorize each tool call" boundary. Its Authorization API 1.0 already defines the interoperable Subject-Action-Resource-Context (SARC) allow/deny decision interface ScopeGate implements ad hoc, and the newly-approved COAZ Working Group Draft (AuthZEN Profile for MCP Tool Authorization, 2026-06-15) profiles MCP tool invocations into SARC, so an API/AI gateway, service mesh, or downstream PDP can authorize a model-emitted tool call at the invocation point. Read against ScopeGate: the same deterministic per-call decision, but a proposed interoperability standard (practitioner-opinion, a Working Group Draft) rather than an empirical, benchmark-tested control — so it is weighted below this paper's measured 0/48 / 0/29 results where they overlap, and carries no equivalent adaptive-attack evaluation. The companion AARP draft adds a shape ScopeGate has no analogue for: instead of a bare DENY, it standardizes a "not yet — here is the prerequisite" approval/attestation/delegation step (generalizing CIBA) before policy is re-evaluated — turning ScopeGate's terminal deny into a resumable governance handshake. The fuller treatment lives on AIMS.

Connections#

• Agent Identity Management System (AIMS) — the standards-body home of the OpenID AuthZEN drafts: AuthZEN's Authorization API + COAZ are the proposed-standard version of ScopeGate's per-call (tool, args) value authorization (a SARC allow/deny at the MCP tool-invocation point), and AARP adds the prerequisite/approval ("not yet") shape ScopeGate lacks — proposed Working Group Drafts, weighted below this paper's empirical measurements (detailed above)
• Off-Host, Identity-Bound Authorization — the off-host sibling: aiAuthZ (Kodathala, arXiv 2607.05518) is the other point on the "where does the authorization boundary live?" axis. Both are deterministic, fail-closed, per-call authorization gates with argument-level allowlists, out-of-band policy, and microsecond latency, sharing the same composition + corrupt-legitimately-variable-data residuals — indeed aiAuthZ's argument-only ablation baseline is essentially ScopeGate's shape. Two precise differences: (1) ScopeGate is an in-framework PDP/PEP (placement-independent by its author's argument), while aiAuthZ insists on a separate trust domain after measuring that a runtime with overlapping built-in tools bypasses even an external gateway; (2) ScopeGate has no caller-authentication step, while aiAuthZ adds per-message HMAC identity of the human sender — worth a measured 9/9 vs 4/9 edge over the argument-only baseline, because it blocks identity-spoofing (a non-owner claiming owner authority) a pure value gate cannot distinguish from legitimate owner use
• Out-of-Band Prompt-Injection Defense — ScopeGate is a member of that out-of-band reference-monitor / PDP-PEP family (CaMeL/FIDES/Progent/RTBAS/FORGE), specialized to per-call value authorization of framework defaults; both share the "policy must be out-of-band, the gate must not be a model" doctrine, and both hit the same in-the-loop / corrupt-the-legitimate-data limit
• Non-Malleable Memory Authority (TMA-NM) — the memory-authority twin of ScopeGate's per-call value authorization: both are deterministic, out-of-band, no-model-in-the-loop gates at the tool boundary (ScopeGate re-authorizes argument values; TMA-NM binds a memory item's authority-to-act to origin), both are ~µs-cheap with no extra model call, both share the corrupt-legitimately-variable-data residual that needs value-level provenance, and both instantiate "authority/policy must be out-of-band, the gate must not be a model" — TMA-NM adds the cross-session memory dimension and a machine-checked non-malleability guarantee
• Agentic Prompt Injection — the threat this assumes and studies the next layer of: injection produces a model-emitted tool call, and this paper asks whether the runtime executes it (it does, by default)
• Least Agency — per-call value authorization is least agency at argument-value granularity: capability gating scopes which tools, ScopeGate's authz stage scopes which argument values, deterministically enforced at the tool-call boundary — the mechanism that makes "restrict what each tool can do" a hard barrier down to the value
• Blast Radius (Agentic) — ScopeGate "makes the compromised model's reachable actions bounded by policy, before side effects": bounding blast radius at the tool-call boundary, the containment (not prevention) posture "assume breach" expects
• Agent Data Injection (ADI) — ADI produces a proposed tool call ScopeGate would gate, and shares the residual: ADI forges data the agent legitimately acts on (spoofed author, fabricated tool result), which satisfies a value policy while doing harm — the same class that survives Progent (22.2%) and ScopeGate's authz stage; the value gate only helps where an allowlist constrains the corrupted argument
• Task-Specification Effects in Prompt Injection (AutoDojo) — AutoDojo's positive result ("real robustness comes from binding the agent's actions to the user's request, not filtering inputs") is the request-derived-trajectory version of this paper's operator-policy value gate; and its task-aligned-injection mechanism is exactly what drives the naive→task-aligned ASR jump (glm-4.7 0.283→1.000) measured here
• MCP Tool Poisoning — the delivery layer this gate assumes: ShareLock defeats detection (all LLM classifiers + entropy) and reconstructs a malicious instruction at runtime, but the reconstructed call (read api_key, exfil to an attacker address) is a model-emitted tool call that lies within granted capability — exactly the confused-deputy-within-scope class ScopeGate's per-call value authz stage denies where an allowlist constrains the argument. Detection-evasion is why the durable defense sits at the authorization layer, not the scanner. Its Agentjacking case study is the in-the-wild version of the same confused deputy: the hijacked agent emits an npx @attacker-package execution + credential-exfil egress — model-supplied argument values a per-call authz allowlist (permitted packages, permitted egress hosts) could deny, while the "fix this Sentry bug" framing is the legitimately-variable residual a value gate can't reach (vendor-reported, weighted below this paper's empirical measurement)
• Agent Identity and Authentication — complementary layers: identity/auth answers who the agent is; per-call authorization answers whether this call is allowed in that principal/session context — the "principal and session context" ScopeGate's authz stage checks against presupposes the attributable identity this control domain establishes
• Zero Trust for AI Agents — the concrete instantiation of the framework's Phase 5 "secure tool access" (parameter validation, approval escalation): the audited frameworks leave complete mediation to the integrator, and ScopeGate is one deterministic implementation of that boundary (hub)
• Impossible, Not Tedious (Design Test) — a deterministic fail-closed gate removes the capability to authorize an off-policy action (default-deny, errors-deny) rather than throttling it; "a policy engine that fails open on malformed input recreates the vulnerability with extra steps" is the test stated as an implementation rule
• Capability-Gated Model Fallback — different sense of "capability" — do not conflate. There, capability = a model's dangerous knowledge level, and the "gate" routes risky queries to a weaker model (fallback-not-refusal). Here, capability = which tools are exposed, and the point is that gating capabilities is not authorizing calls. Same word, orthogonal mechanisms (query-level model routing vs tool-call-level value authorization)
• OWASP — the confused-deputy failure is indirect prompt injection under OWASP LLM01 (and MITRE ATLAS AML.T0051); the paper studies the mediation layer OWASP's threat implies
• LangChain/LangGraph, LlamaIndex, and the Stripe Agent Toolkit are the audited frameworks (referenced as plain text — no entity pages)

Open Questions#

• The 0/48 static and 0/29 adaptive results are suite- and budget-bounded (40 iterations, a GLM-5.2 attacker, one author's vector corpus). Does the deterministic gate hold under longer adaptive budgets, stateful side channels (DNS rebinding, timing), or multi-agent policy-poisoning — the future work the paper names?
• The authz allowlist stops value-redirection but not corruption of legitimately-variable data. Is there a per-call scheme that constrains free-text / open-ended arguments without collapsing utility — or is that irreducibly the province of provenance/data-flow tracking (CaMeL Strict, at ~50pp utility cost)?
• The deployment-tier ~3.2× exposure gap (0.603 vs 0.189) means the cheap models chosen for high-volume agent traffic are the most likely to emit the unauthorized call — exactly where a per-call gate is most load-bearing. Does model improvement shrink the attempt rate enough that the gate becomes optional, or is the gate the durable control while models stay jagged?
• Out-of-band policy is load-bearing but under-specified for authoring at scale. The paper forbids any model-sourced policy element; who authors and maintains the verified sets, ceilings, and allowlists for a large tool surface, and does that authoring burden cap the control to high-stakes (money-moving) tools?
